Geysir Bedpan washer
LISCHKA bedpan washers combine the technical level of modern brand-name equipment with the experience gained from decades of customer corporation in service and sales. With the Geysir series, we have realized a novel, variable solution concept that backs up efficiency and convenience with uncompromising performance. The innovative cleaning system consisting of multifunctional power nozzles, maintenance-free labyrinth door seal and patented re-cooling system cleans and disinfects in the required disinfection quality (according to EN ISO 15883-1/3). The system can also easily meet higher hygiene requirements with its 99 wash programs and freely selectable cleaning and disinfection levels in accordance with the standard.
CDD 1050
The Geysir CDD 1050 is a versatile, space-saving combination appliance with a large washing chamber and ergonomic loading height. This easy-to-use model can be used to meet almost all standard and even special installation requirements.
It impresses with its compact design. It has integrated space for up to 2x5L chemical containers. The Geysir CDD 1050 is the right choice when it comes to effectively and efficiently reprocessing utensils in accordance with the latest hygiene regulations, even in the smallest of spaces.
Technical data CDD 1050
| Cold water: | 5-35°C | Electrical connection: | 400V 3N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 4,85kW |
| Flow rate: | 18l/min | Fuse: | 10A |
| Water pressure: | 0,8 – 8bar | Alternate | |
| Hot water | 40-60°C | Electrical connection: | 230V 1N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 3,85kW |
| Flow rate: | 18l/min | Fuse: | 16A |
| Water pressure: | 0,8 – 8bar | Cable length: | 1200mm |
| Drainage: | DN100 | ØNoise emission LpA: | 50dB |
CDD 1060
The Geysir CDD 1060 is the smallest compact device in the Geysir series. Small in size yet effective and efficient in cleaning, these are the impressive features of this device. The use of this narrow model with an unchanged large washing chamber guarantees the most optimal use of space in terms of the equipment of the work care combination. The Geysir CDD 1060 is the right choice when it comes to effectively and efficiently reprocessing utensils in accordance with the latest hygiene regulations, even in the smallest of spaces, without compromising on the working height of 900 mm.
Technical data CDD 1060
| Cold water: | 5-35°C | Electrical connection: | 400V 3N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 4,85kW |
| Flow rate: | 18l/min | Fuse: | 10A |
| Water pressure: | 0,8 – 8bar | Alternate | |
| Hot water | 40-60°C | Electrical connection: | 230V 1N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 3,85kW |
| Flow rate: | 18l/min | Fuse: | 16A |
| Water pressure: | 0,8 – 8bar | Cable length: | 1200mm |
| Drainage: | DN100 | ØNoise emission LpA: | 50dB |
CDD 1090
The Geysir CDD 1090 is a large, practical device. It is also fully under-counter compatible and has integrated space for up to 2 x 5 litre chemical containers. By installing a hand wash basin in the worktop above the unit, it can be easily integrated into work care combinations without losing the optimum working height of 900 mm. It thus blends harmoniously into the room. The Geysir CDD 1090 is the right choice when it comes to effectively and efficiently preparing utensils in accordance with the latest hygiene regulations and you need an all-rounder.
Technical data CDD 1090
| Cold water: | 5-35°C | Electrical connection: | 400V 3N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 4,85kW |
| Flow rate: | 18l/min | Fuse: | 10A |
| Water pressure: | 0,8 – 8bar | Alternate | |
| Hot water | 40-60°C | Electrical connection: | 230V 1N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 3,85kW |
| Flow rate: | 18l/min | Fuse: | 16A |
| Water pressure: | 0,8 – 8bar | Cable length: | 1200mm |
| Drainage: | DN100 | ØNoise emission LpA: | 50dB |
Customized
Work care combinations
At Lischka you get the perfect combination of bedpan washers and medical furniture with our Geysir work care combinations.
CDD 1050 E / CDD 1050 EWC
The Geysir CDD 1050 E is suitable for wall mounting and offers an ideal solution for a proper instalation in the wall. Above the unit there is a cabinet for storing chemical canisters. The Geysir CDD 1050 EWC also offers the option of integrating a wall-mounted, commercially available WC and is therefore perfect for equipping ICU and isolation rooms. A toilet cistern and the flush button are already included in this design.
Technical data CDD 1050 EWC
| Cold water: | 5-35°C | Electrical connection: | 400V 3N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 4,85kW |
| Flow rate: | 18l/min | Fuse: | 10A |
| Water pressure: | 0,8 – 8bar | Alternate | |
| Hot water | 40-60°C | Electrical connection: | 230V 1N/PE (50/60Hz) |
| Connection: | R3/4″ | Nominal power: | 3,85kW |
| Flow rate: | 18l/min | Fuse: | 16A |
| Water pressure: | 0,8 – 8bar | Cable length: | 1200mm |
| Drainage: | DN100 | ØNoise emission LpA: | 50dB |
Frequently asked questions (FAQ)
Yes, bedpan washers are generally Class IIa medical devices and have to be certified.
The GEYSIR series bedpan washers are available in the following dimensions: WxDxH 500x450x1775 mm (CDD 1050), 500x600x1775 mm (CDD 1050), 600x600x1200 mm (CDD 1060 basic), 600x560x860 mm (CDD 1060 classic, can be installed under a counter), 900x560x900 mm (CDD 1090 classic, can be installed under a counter) and 900x600x900 mm (CDD 1090 basic).
Since bedpan washers are essentially technical devices, they must be serviced once a year. This maintenance also includes the measurements required by law in accordance with DGUV regulations and a measurement to verify A0 value.
The GEYSIR series bedpan washers feature a storage rack that is directly accessible after opening the washing clamp door and can be loaded very easily and intuitively loaded.
The GEYSIR series of bedpan washers monitor all reprocessing steps within the device itself, and only when all reprocessing parameters have been met are the utensils cleared for removal.
